White glue production line

1.What is white emulsion?

The white emulsion is a Water-based adhesive. In generally, we can call it white glue or PVAC emulsion.
It\'s widely used for sticking paper products, waterproof coatings and wood adhesives.

2.The production process of white emulsion:
1) Put the raw materials and emulsifier into tank for emulsification,filtration,got the PVAC monomer.
2) Put PVAC emulsified monomers and initiator into a stainless steel reactor,stirring, and fully mixed.
3) Stop heating, control the temperature below 80 ℃, put PVAC monomers and initiator into reactor again,and all the raw materials should be finished add in 8 hours.
4) Keeping the temperature in 93 ℃ for 30 minutes, and the polymerization reaction is finised
5) Cooling , control the temperature below 50 ℃,and add additive for adjusting the PH .
6) Reactor keeps stirring in whole production process .when it cooled to room temperture, stop stirring,filter and package.

3.The white emulsion production line equipment :
1) Initiator tank 1 set.
2) Emulsifying equipment 1 set.
3) Reactor 1set
4) Cooling system.
5) Filtration system.
6) Other.


Widely used in furniture manufacturing,adhesives for paper,wood,cloth ,leather, ceramics etc. also for phenolic resins, urea-formaldehyde resin adhesive modifier, for the manufacture of polyvinyl acetate latex paint and so on.

The technical parameter of chemical reactor:

1）Equipment volume: 20-50000L (volume in accordance with the requirements of the design.)

2 ) Reaction temperature : -20℃~300℃。

3 ) Reaction pressure -0.1~1.6Mpa.

4 ) Equipment Material : SS304 , SS321 , SS316L stainless steel ; Q235-B carbon steel.

5 ) Mixing type: blade type, anchor type, frame type, screw belt type, turbine type,

dispersing disc type, combination type and so on.

6 ) Heating method: the heat conduction oil circulation heating, Electric heating in jacket，

steam heating, hot water heating.

7) Transfer structure: the outer jacket, the outer half tube, inner tube.

Contact information:

If you need to know the detailed equipment configuration, production technology, production
process, please contact us.
