How to measure the technical parameter of dispersion mixer

Model

Cylindervolume（L）

Motorpower（KW）

Stirring speed（rpm）

Remarks

total volume

Feeding quantity

Low speed mixing

High speed dispersion

Low speed mixing

High speed dispersion

QF-5

5

4

0.75

0.75*2

23

0-1000

Table data for reference, actual data according to the specific process requirements, material viscosity, etc.

QF-20

20

16

1.1

1.1*2

23

0-1000

QF-50

50

40

1.5

2.2*2

23

0-1000

QF-100

100

80

3

5.5*2

23

0-1000

QF-200

200

160

4

7.5*2

23

0-1000

QF-300

300

240

5.5

15*2

23

0-1000

QF-500

500

400

7.5

22*2

23

0-1000

QF-1000

1000

800

18.5

30*2

0-20

0-1000

QF-2000

2000

1600

30

37*2

0-20

0-1000

QF-3000

3000

2400

30

45*2

0-20

0-1000

QF-4000

4000

3200

37

55*2

0-20

0-1000

QF-5000

5000

4000

45

55*2

0-20

0-1000

1、Lift mode: hydraulic lift

2、The mixing tank with a clip, can be heated and cooled according to the need;

3、Pressure range: -0.1~0.3MPa;

4、Speed control mode: frequency converter.
